3EO110-250 (110H3S250)
Brand: hqm
Code: 3EO110-250
Phase: 3
Weight (kg): 11
Torque (NM): 20
Lead: 3
Buy Online
Send a Message
The add to cart button will appear once you select the values above
Technical Details
Details
Accessories
Downloads
Videos
Weight (kg)
11
Motor length(mm)
220
Detent Torque (N.cm)
68
Inertia (g.cm)
19600
Lead
3
Resistance (ohm)
1.5
Inductance (mH)
20
Current (A)
6
Torque (NM)
20
Step Angle
1.2
Phase
3
