3EO86-90 (86H3S90)
Brand: hqm
Code: 3EO86-90 (86H3S90)
Phase: 3
Weight (kg): 4.5
Torque (NM): 9.2
Lead: 3
Buy Online
Send a Message
The add to cart button will appear once you select the values above
Technical Details
Details
Accessories
Downloads
Videos
Weight (kg)
4.5
Motor length(mm)
150
Detent Torque (N.cm)
-
Inertia (g.cm)
2500
Lead
3
Resistance (ohm)
0.7
Inductance (mH)
3.5
Current (A)
6.8
Torque (NM)
9.2
Step Angle
1.2
Phase
3
