110HS200
Brand: hqm
Code: 110HS200
Phase: 2
Weight (kg): 8.4
Torque (NM): 21
Lead: 4
Buy Online
Send a Message
The add to cart button will appear once you select the values above
Technical Details
Details
Accessories
Downloads
Videos
Weight (kg)
8.4
Motor length(mm)
150
Detent Torque (N.cm)
59
Inertia (g.cm)
10900
Lead
4
Resistance (ohm)
0.75
Inductance (mH)
11
Current (A)
6.5
Torque (NM)
21
Step Angle
1.8
Phase
2
