86HS65
Brand: hqm
Code: 86HS65
Phase: 2
Weight (kg): 3
Torque (NM): 7
Lead: 8
Buy Online
Send a Message
The add to cart button will appear once you select the values above
Technical Details
Details
Accessories
Downloads
Videos
Weight (kg)
3
Motor length(mm)
98
Detent Torque (N.cm)
9.5
Inertia (g.cm)
2000
Lead
8
Resistance (ohm)
0.4
Inductance (mH)
4.2
Current (A)
6
Torque (NM)
7
Step Angle
1.8
Phase
2
