57HS22
Brand: hqm
Code: 57HS22
Phase: 2
Weight (kg): 1.2
Torque (NM): 2.2
Lead: 4
Buy Online
Send a Message
The add to cart button will appear once you select the values above
Technical Details
Details
Accessories
Downloads
Videos
Weight (kg)
1.2
Motor length(mm)
83
Detent Torque (N.cm)
8
Inertia (g.cm)
560
Lead
4
Resistance (ohm)
0.65
Inductance (mH)
2.5
Current (A)
42
Torque (NM)
2.2
Step Angle
1.8
Phase
2
