42HS04
Brand: hqm
Code: 42HS04
Phase: 2
Weight (kg): 0.35
Torque (NM): 0.4
Lead: 4
Buy Online
Send a Message
The add to cart button will appear once you select the values above
Technical Details
Details
Accessories
Downloads
Videos
Weight (kg)
0.35
Motor length(mm)
40
Detent Torque (N.cm)
2.2
Inertia (g.cm)
54
Lead
4
Resistance (ohm)
1.5
Inductance (mH)
2.8
Current (A)
1.7
Torque (NM)
0.4
Step Angle
1.8
Phase
2
