FF 25
Dimensions
Brand: hqm
Model: FF 25
Diameter: 25
Suitable for ballscrew and leadscrew
Buy Online
Send a Message
The add to cart button will appear once you select the values above
Technical Details
Details
Accessories
Downloads
Videos
Dimensions
d1
25
L
24
B
79
H
14
X
9
Y
14
z
8.5
F
10
Dg6
63
A
98
PCD
80
