SFS 1616-1.8
Dimensions
Brand: hqm
Model: SFS 1616-1.8
Diameter: 15
Lead: 16
Number of circuite: 1.8x1
Suitable for industrial and CNC machines
Buy Online
Send a Message
The add to cart button will appear once you select the values above
Technical Details
Details
Accessories
Downloads
Videos
Dimensions
d
15
Lead
16
Ball Dia
2.778
D
28
A
48
B
10
L
45
W
38
X
5.5
H
40
Q
M6x1
Number of circuite
1.8x1
Basic Dynamic Rating Load
552
Basic Static Rating Load
1137
