DFI2505-3
Dimensions
Brand: hqm
Model: DFI2505-3
Diameter: 25
Lead: 5
Number of circuite: 3
Suitable for industrial and CNC machines
Buy Online
Send a Message
The add to cart button will appear once you select the values above
Technical Details
Details
Accessories
Downloads
Videos
Dimensions
d
25
Lead
5
Ball Dia
3.175
D
40
A
63
B
10
L
86
W
51
X
5.5
H
46
Q
M8
Number of circuite
3
Basic Dynamic Rating Load
980
Basic Static Rating Load
2300
Stiffness
57
Y
9.5
Z
5.5
